New GaN powered 1.2kW PSU offers high efficiency in small footprint
New from Enedo Power; the HDP1200, a 1200W AC-DC power supply powered by GaN (Gallium Nitride) Wide Bandgap FETs. This advanced technology enables faster switching, lower losses, and up to 95.5% efficiency, achieving twice the power density in a compact and quiet 1U design, according to Luso Electronics.
Engineered for medical, industrial, AV/IT, and LED lighting applications, the HDP1200 is designed to deliver future-proof performance in a compact form factor, setting a new benchmark for efficiency and reliability.
Coming with its own embedded fan there are two variants available at the moment, with 24V or 48V outputs. The HDP1200 provides a steady 1200 W of regulated DC power through the 180 to 305 VAC input range, all in a 4.2 x 8.1 x 1.6” format.
With 95% efficiency, the HDP1200 generates less heat, facilitating optimal thermal management in space constrained environments, resulting in very high reliability. Being digitally controlled the front-mounted fan rotation speed guarantees the minimum required airflow, minimizing audible noise for quiet operation, and enhancing the power supply service lifetime.
The HDP1200 features a built-in I-share circuit for parallel operation between power units to enhance total power. It also features a range of protection features and control signals.
The series is approved to the IEC 60601-1 safety standard for medical equipment, offers 2x MoPP means of patient protection, and is suitable for BF rated medical equipment. It is also certified to the latest edition of the IEC 62368-1 standards for Audio Video and IT equipment and complies with UL8750 for LED lighting applications.
Highlights and Features:
- Universal input voltage range (85 – 305 VAC)
- Inrush current limiting
- 1200 W rated power
- 95% typical efficiency
- Active GaN based PFC, EN61000-3-2 Class C
- Fan speed control circuit
- Full set of electrical and thermal protections
- Standby +5 V, 1.5 A
- Current sharing signal for parallel operation
- Remote On / Off and Power Good signals
- Medical safety approval to IEC 60601-1, 2x MoPP: BF appliance compatible
- IEC 60601-1-2 4th edition EMC compliant.
- AV&IT safety approval to IEC 62368-1
- Design compliant to UL8750 for LED Lighting
- Medical version compatible with 4000 m altitude operation
Sampling now, full production units will be available from Luso Electronics in Summer 2026.
Please contact Luso Electronics’ product specialists who will assist with product selection and guide you through the design cycle; offering both technical and commercial support.
